- Model: FZL-P30V300; FZL-P30V500; FZL-P40V440; FZL-P40V590
- Temperature Range: -10 to -30 °C, -20 to -40 °C
- Sensor: NTC
- Temperature Controller: Microcomputer Control
- Cooling Mode: Direct Cooling
- Defrost Mode: Manual
Low Temperature Freezer, Pharmacy Refrigerator
Warning: call_user_func_array() expects parameter 1 to be a valid callback, function 'wpb_pcf_contact_form_button' not found or invalid function name in /www/wwwroot/www.labpeak.com/wp-includes/class-wp-hook.php on line 341
A low-temperature freezer designed for the low-temperature preservation of biological products such as bacteria, viruses, plasma, vaccines, red blood cells and white blood cells. It is suitable for hospitals, pharmaceutical factories, pharmacies, centers for disease control and prevention, health service centers, as well as laboratories of various universities and research institutes.
Low Temperature Freezer Feature:
- Microcomputer-controlled temperature regulation with digital temperature display.
- Stainless steel shelves and interior liner, corrosion resistance and ease of cleaning.
- Equipped with an inverter compressor that automatically adjusts operating frequency based on the cooling load, ensuring greater temperature stability and energy efficiency.
- Built-in data storage module capable of storing 10 years of temperature data, along with a USB port for data export.
- Multiple alarm functions and modes, as well as comprehensive safety protection features.
- Equipped with a backup battery to ensure that internal temperature readings and alarm information remain visible during power outages.
Low Temperature Freezer Specifications:
| Model | FZL-P30V300 | FZL-P30V500 | FZL-P40V440 | FZL-P40V590 |
| Capacity (L) | 300 | 500 | 435 | 590 |
| Temperature Range | -10 to -30 °C | -20 to -40 °C | ||
| Sensor | NTC | |||
| Temperature Controller | Microcomputer Control | |||
| Cooling Mode | Direct Cooling | |||
| Cooling Liquid | R290/75g | R290/110g | R290/120g | R290/135g |
| Defrost Mode | Manual | |||
| Compressor Qty | Inverter compressor/1 | |||
| Shelf/Drawer Qty | 3 | |||
| Rack | / | 12(5×5) | 12(5×5) | 16(5×5) |
| Storage Capacity (2 Inches Boxe) | / | 300 | 300 | 400 |
| Samples (2 mL) | / | 30000 | 30000 | 40000 |
| Comsuption (W) | 145 | 175 | 180 | 200 |
| Daily Power Consumption (W) | 2.34 | 2.75 | 2.6 | 2.75 |
| Noise (dB) | 40 | 42 | ||
| Power Supply | 220/110 V, 50/60 Hz | |||
| Display | Digital Display | |||
| Inside Material | SUS304 | |||
| Outside Material | Powder-coated Cold-rolled Steel Plate | Cold Plate Spray Coating | ||
| Alarm | High/low temperature, Power failure, Sensor error, Thermostat failure, Low battery, High ambient temperature, Door ajar, Power failure alarm (for controller) | High/low temperature, Power failure, Abnormal voltage, Sensor error, Thermostat failure, Low battery, High ambient temperature, Door ajar, Power failure alarm (for controller) | ||
| Exterior Size (W×D×H)(mm) | 695×708×1880 | 695×993×1880 | 695×1013×1880 | 845×1013×1880 |
| Package Size (W×D×H)(mm) | 762×765×2048 | 780×1065×1983 | 795×1085×1994 | 945×1085×1994 |
| Accessory | 4 pcs. Castor; | 4 pcs. Castor; | ||
| 1/Foamed Outer door | 4 Inside door | |||
| 2 pc Test hole, 25 mm diameter; | 2 pc Test hole, 25 mm diameter; | |||
| Door Lock | USB port | |||
| USB port | RS485 port (Optional) | |||
| Data logger | Data logger | |||
| Remote alarm port | Remote alarm port | |||
| N.W./G.W. (kg) | 115/135 | 150/175 | 145/170 | 180/200 |
FAQ
Why is temperature stability so important?
Medicines (especially vaccines and biologics) are extremely sensitive to temperature fluctuations. Temperature fluctuations can lead to reduced efficacy or even render the medication ineffective; therefore, a consistently stable refrigerated environment must be maintained.
Can regular food be stored in it?
This is not recommended. Medication refrigerators should be used exclusively for medical purposes to avoid cross-contamination and temperature fluctuations caused by frequent door openings, which can affect the stability of the medication.
What is the temperature range?
The temperature range is 2°C–8°C. This range is suitable for most vaccines, insulin, and biologics, preventing damage caused by freezing or overheating.
How does it differ from a household refrigerator?
Pharmaceutical refrigerators offer higher temperature control precision, better temperature uniformity, and professional alarm systems, whereas household refrigerators experience greater temperature fluctuations and cannot meet pharmaceutical storage standards.
Are there any certification requirements?
This pharmacy refrigerator complies with CE, FDA, and other certifications and must also meet GSP/GMP regulations in the pharmaceutical sector.
