Combining hydrogen peroxide gas with low-temperature plasma, this solution provides a low-temperature, rapid, and efficient sterilization solution for heat and moisture-sensitive precision medical devices. Ideal for sterilizing complex instruments such as rigid/flexible endoscopes, electronic instruments, polymer materials, the medical aesthetics industry, and surgical implants. The sterilization cycle is shortened to 28 min; hydrogen peroxide sterilant breaks down into water and oxygen, ensuring an environmentally friendly sterilization process.

Hydrogen Peroxide Low Temperature Plasma Sterilizer Feature:

Highly efficient sterilization, environmentally friendly: Low-temperature sterilization process, preserving heat-sensitive and fragile instruments, fully compatible with precision instruments.
Dual sterilization temperature protection balances effectiveness and safety: Stable temperature, humidity, and hydrogen peroxide concentration; hexahedral PTC silicone plate (independent temperature control).
Fully automatic PLC control with a 7-inch LCD touchscreen: one-button start, easy operation, and support for five languages, including Chinese, English, Spanish, and Russian.
Rectangular sterilization chamber structure + 304 stainless steel chamber: Large capacity, high space utilization, excellent thermal conductivity, and resistance to deformation. Electrostatically painted 304 stainless steel outer shell, durable and easy to clean.
Cartridge-type sterilant: Each cartridge contains 12 capsules, with an H₂O₂ dosage error of ≤1%, pH of ≤2.6. Features capsule counting memory function and a low-remaining-residue alarm.
Environmental compliance: A 0.22 μm sterile air intake filter prevents secondary contamination, whilst a dual exhaust filtration system ensures that the ambient hydrogen peroxide concentration remains below 0.6 mg/m³.
Safe and stable operation: Electric lifting door with safety interlock, H₂O₂ corrosion-resistant rotary vane vacuum pump (pumping capacity 16 m³/h, noise < 65 dB).
Built-in biological indicator incubator with independent control, allowing convenient biological indicator testing even when the device is not in operation.
Data and traceability verification: Supports data storage on USB sticks and real-time printing via a mini printer, capable of storing complete sterilization records ≥ 8,000.
Automatic system detection, fault alarms, and maintenance reminders reduce operating costs and extend equipment lifespan.

Hydrogen Peroxide Low Temperature Plasma Sterilizer Specifications:

Model	STL-PHT60P	STL-PHT110P	STL-PHT130P	STL-PHT160P	STL-PHT180P	STL-PHT200P	STL-PHT300P	STL-PHT400P
Capacity (L)	60	110	130	160	180	200	300	400
Door Type	Automatic door vertical
Electric Heating	Electric heating
Working Temperature	50±3°C
Hydrogen Peroxide Concentration	58% (Standard);
Hydrogen Peroxide Concentration	Hydrogen peroxide purification technology, 95%±5% (optional);
Hydrogen Peroxide Cartridge	Each cartridge contains 12 individual capsules. Single H₂O₂ dosage error: ≤ ±1%; pH value: ≤ 2.6 (acidic)
Total Cycle Time	Rapid sterilization time ≤ 45 min;
	Standard sterilization time ≤ 65 min;
	Enhanced sterilization time ≤ 85 min.
Power Supply	AC 220/110 V, 50/60 Hz						AC 380/220 V, 50/60 Hz (three-phase)
Consumption (kW)	2.2	2.8	3.8	4	4.2	4.6	4.8	5
Chamber Size (W×D×H)(mm)	620×350×280	610×480×380	710×480×380	770×460×460	860×460×460	960×460×460	960×560×560	1010×660×600
External Size (W×D×H)(mm)	770×660×1400	760×790×1600	860×790×1600	920×770×1760	1010×770×1760	1110×770×1760	1110×870×1960	1160×1165×1950
Shipping Size (W×D×H)(mm)	970×830×1720	960×890×1800	970×890×1800	1140×990×1960	1230×990×1960	1230×990×1960	1300×1070×2260	1380×1385×2150
N.W./G.W. (kg)	233/263	295/335	300/340	320/365	340/385	360/400	396/456	500/560
