| External Size (W×D×H)(mm) |
900×1050×2275 |
1200×1050×2275 |
1500×1050×2275 |
1800×1050×2275 |
| Internal Size (WxDxH)(mm) |
770×500×900 |
1070×500×900 |
1270×500×900 |
1570×500×900 |
| Max Opening |
750mm |
| Work Surface Height |
800mm |
| Spray System |
Double Channel Spray (with double scrubber) |
| PH Value |
PH Value Display, support 485 communication protocol |
| Control System |
Display |
4.3″ LCD touch screen |
| Alarm |
With Leakage alarm system |
| Airflow System |
Airflow Velocity |
0.3-0.5m/s, speed adjustable |
| Air Volume |
1000m³/h |
1200m³/h |
1600m³/h |
1800m³/h |
| Exhaust Outer diameter |
Φ160mm |
Φ250mm |
Φ250mm |
Φ300mm |
| Cabinet Construction |
Main Body |
PP (polypropylene) material |
| Work Surface |
PP (polypropylene) material |
| Front Window |
Manual door, PVC material |
| Electrical System |
LED Lamp |
2×30W |
| Max.Consumption |
200W (Not include socket loading power consumption) |
| Power Supply |
AC 220V±10%, 50/60Hz, 110V±10%, 60Hz |
| Illumination |
800Lux |
| Sound Emission |
≤60dB(A) |
| Standard Accessory |
Air Velocity Sensor, Gas & Water Tap and Valve, Waterproof Socket×4, Electric Air Valve, LED Lamp×2, Water Pump, Double Washing System, Automatic Dosing System |
| Optional Accessory |
Epoxy Resin Work Surface, 0.3KW Centrifugal Blower, VAV variable air volume system |
| Net Weight(kg) |
160 |
250 |
300 |
380 |
| Gross Weight (kg) |
Main Body |
150 |
220 |
270 |
300 |
| Base Cabinet |
90 |
120 |
150 |
180 |
| Shipping Size (W×D×H)(mm) |
Main Body |
1050×1270×1780 |
1350×1270×1780 |
1650×1270×1780 |
1950×1270×1780 |
| Base Cabinet |
1050×1220×1020 |
1350×1220×1020 |
1650×1220×1020 |
1950×1220×1020 |
| Shipping Volume (m³) |
3.7 |
4.8 |
5.8 |
6.9 |
